Sale!
Flat Wire Common Mode Choke – MTFWC1010103V
Original price was: ₹120.00.₹100.00Current price is: ₹100.00.
You save
FEATURES
- Reduce Skin Effect
- Flat Wire Construction
- High Current Capability
- Low magnetic flux leakage
- Easy to mount on PCB circuits
- High common mode impedance at high frequencies
- Operating temperature: –25 ºC to +125 ºC
Datasheet
10 in stock
APPLICATIONS
- White Goods
- DC-DC converter
- AC-DC Converters
- Power Supplies (SMPS)
- Input Filter for Mains Power Lines
