SMD Common Mode Choke

MTDSCMC0805361

₹40.00 ₹35.00

  • SMD Common Mode Choke
  • Order Code: MTDSCMC0805361
  • Impedance, Z @100 MHz = 360 Ω
  • DCR = 0.55 Ω
  • Rated Current = 280 mA
  • Size: 2.0 mm x 1.2 mm (0805)

Datasheet

For bulk quantity inquiry, email us at sales@magnoteknik.com

100 in stock

Quantity Price
1 - 499 ₹35.00
500 - 999 ₹30.00
1,000+ ₹25.00

Order Code : MTDSCMC0805361

FEATURES
  • Low DC resistance
  • Ferrite core material
  • Current compensated choke
  • MD version for an easy installation on the PCB
  • Operating voltage: up to 80 Vdc or 42 Vac
  • Operating temperature: –40 ºC to +125 ºC
APPLICATIONS
  • EMI Suppression
  • Noise Attenuation
  • Wide Band Filtering
  • Power Supplies (SMPS)
  • Input Filters of DC-DC Converters

Other Inductance values are also available in same package size:
